Details The 5 Bar MAP Variohm Eurosensor reads up to 4 Bar absolute pressure. This means that it is suitable for turbo or supercharged applications running up to 4 Bar (or 58psi) of boost pressure. Includes Plug and Pins Push wire through connector; crimp on terminal; pull wire/terminal back into connector Using Link G4/G4+/G4X ECU’s select the MAP sensor type in PC Link as ‘Variohm 5 Bar’ Calibration - 0kpa = 0.5v, 500kpa = 4.5v PIN A = 0v PIN B = 5v PIN C = Signal

Link ECU

5 Bar MAP Sensor EU (MAP5EU)

SKU LINK101-0295

Regular price: $343.85

Details The 5 Bar MAP Variohm Eurosensor reads up to 4 Bar absolute pressure. This means that it is suitable for turbo or supercharged applications running up to 4 Bar (or 58psi) of boost pressure. Includes Plug and Pins Push wire through connector; crimp on terminal; pull wire/terminal back into connector Using Link G4/G4+/G4X ECU’s select the MAP sensor type in PC Link as ‘Variohm 5 Bar’ Calibration - 0kpa = 0.5v, 500kpa = 4.5v PIN A = 0v PIN B = 5v PIN C = Signal

Regular price: $343.85

Quantity

Product Description

Details The 5 Bar MAP Variohm Eurosensor reads up to 4 Bar absolute pressure. This means that it is suitable for turbo or supercharged applications running up to 4 Bar (or 58psi) of boost pressure. Includes Plug and Pins Push wire through connector; crimp on terminal; pull wire/terminal back into connector Using Link G4/G4+/G4X ECU’s select the MAP sensor type in PC Link as ‘Variohm 5 Bar’ Calibration - 0kpa = 0.5v, 500kpa = 4.5v PIN A = 0v PIN B = 5v PIN C = Signal
